THE MOBILE WORKSHOP SOLUTION FOR BIKE PROFESSIONALS

The e-bike lifter developed by by,schulz is designed for bicycles, e-bikes and cargo bikes. The system enables bicycle mechanics to work flexibly and conveniently in the service workshop.
The solid battery-powered design is combined with a solid aluminum lifting column and internal toothed belt drive. Two foot pedals integrated into the steel base plate allow easy lift operation by foot.

Combined with a sensitive stop system, it enables the mechanic to raise and lower the clamped bike continuously with a safety function.
The stable base plate is equipped with four adjustable feet for a floor leveling function. This assembly stand combines many practical features and is the perfect new purchase to meet future requirements in the bicycle service sector.

Mobile use

High load capacity

Foot operation

Safety function

Battery operation

EU guidelines

FEATURES

Foot pedal

Two foot pedals integrated into the steel floor plate allow easy lift operation by foot. Combined with a sensitive stop system, this allows the mechanic to raise and lower the clamped bike continuously. The stable base plate is also equipped with four adjustable feet for a floor leveling function.

Transport rollers

The entire e-bike lift can be easily moved by one person using the high-quality transport rollers on the rear-mounted handles of the lifting column. The built-in rechargeable batteries enable an autonomous power supply and therefore flexible and mains-independent operation in the workshop, showroom or during events.

Basic mounting plate

The universal clamp arm mount of the base mounting plate with an inner diameter of 50 mm allows the use of many different commercially available clamp arms, e.g. from VAR, Feedback Sports, Park-Tool and others.

Handholds

The e-bike lift can be easily gripped and moved using two handles mounted on the back of the lifting column.

Sliding blocks

The vertical longitudinal grooves on both sides of the lifting column allow optional shelves and holders to be attached at the desired height using sliding blocks. Two sliding blocks with an M6 thread are included in the scope of delivery for each slot. A practical solution for adapting the workstation to your own conditions.

MODELS

e-BikeLifter BM-60

Basic version with base mounting plate

e-BikeLifter BM-60 VA

with clamping arm from VAR

e-Bikelifter BM-60 FB

with clamping arm from Feedback Sports

ACCESSORIES

Feedback Sports Pro Elite Commercial

Can be swiveled through 360° and is suitable for clamping pipes with diameters from 19 to 48 mm. It is easy to operate thanks to a quick ratchet lock with an adjusting screw for fine adjustment of the clamping force and a convenient one-button release.

VAR PR-72000

The oversized clamp can be quickly adapted to any frame tube up to 80 mm. Thanks to the rubber clamp covers, it has excellent frame clamping. The micro-adjustable clamping pressure prevents damage to thin-walled tubes.

Tool holder GR 10 / M

With the magnetic tool holder, you always have your tools to hand and neatly organized. The height of the tool holder can be adjusted and it can also be rotated backwards if required.

(The tools shown are not included in the scope of delivery)

Bottle holder N2 / S2

Maintenance spray and brake cleaner, for example, can be stored within easy reach in the side-mounted bottle holders.

Aluminum profile holder with magnetic shell

The magnetic tray is protected against accidental drops by a magnetic strip attached to the holder. Screws and other small parts can be collected and stored in the tray.

Clipboard A4 / clip clamp

The magnetic clipboard can be conveniently attached to many positions on the e-bike lift. This means that service orders and notes are always visible.

Display holder RL - W

The rotatable and angle-adjustable display holder allows you to position the laptop or tablet directly at the workstation and process orders digitally.

Sliding block

By placing sliding blocks in the longitudinal groove of the e-bike lift, you have the option of attaching attachments and accessories and adjusting their height individually.

Magnetic hook

The magnetic hook is guaranteed to always point in the desired direction. The solidly manufactured magnetic hook can be rotated freely all round, making alignment easier.

VIDEO

YouTube

We embed our videos via the YouTube platform. When playing the video, a data transmission to the USA takes place. By clicking the button "Watch video now", you expressly consent to a corresponding data transmission to the USA and thus an "unsafe third country". We expressly point out that currently the transfer takes place without the existence of an adequacy decision and without guarantees, which is associated with corresponding risks (access to data by US authorities). For more details, please refer to our
Privacy policy

Watch video now

Product
Preview

This video briefly presents the basic functions in a practical application example. You are also welcome to test the e-bike lifter on site at our company headquarters and see for yourself. Simply make an appointment with us by telephone.

FEEDBACK

CUSTOMER FEEDBACK

“The BM-60 e-bike lifter provides us with super flexible support in the workshop. We can finally turn the pedelecs and bikes 360° and carry out every work step ergonomically.”

Rüdiger Jansen – Owner

“Thanks to the mobility of the e-bike lifter, we can also offer our customers a bike check-up outside the workshop. We see the great advantage of not being tied to one place and being able to mount bikes flexibly, even in a smaller workshop area. We are particularly amazed by the speed and battery performance. A super device that we use several times a day!” Max Hertel – Head of Mobility Center

“We can set up the e-bike lift flexibly without having to drill holes in the floor.
It is quick and easy to operate and remains absolutely stable, even when an e-bike has ridden all the way to the top.”

Ludger Lammert – Owner

DISTRIBUTION

To order

For commercial customers and bicycle dealers

If you are interested in a BM-60 assembly stand, you can arrange an order and shipping by phone or e-mail with us personally:
Phone.: +49 (0) 681 – 95 97 25 0
E-Mail: info@e-bikelifter.com

Private customers or end consumers

If you are a bike enthusiast and are also excited about the e-bike lifter, you can purchase the product from the official by,schulz online store.

INFOS

The e-bike lift developed by by,schulz is the result of the successful cooperation between the Danish company Hovmand and the German company by,schulz. This cooperation resulted in a mobile and solid lifting device in workshop quality, which was specially developed for bicycles, e-bikes and cargo bikes. With the integrated transport rollers and the two built-in, powerful batteries, the by,schulz e-bike lifter offers the flexibility and endurance to work wherever you want.

The development of the e-bike lifter has opened up a new segment of the market and by,schulz has set itself the task of simplifying work in the workshop. The result of the successful collaboration between Hovmand and by,schulz is the BM-60 assembly stand, which is produced by Hovmand in Køge, the leading manufacturer of mobile, battery-powered lifting equipment.



· Overall height: approx. 1950 mm
· Base plate dimensions: approx. 600 x 900 mm with 4 adjustable feet
· System weight: approx. 60 kg
· Lifting load: max. 60kg
· Foot switch in base plate / stop system
· Batteries: 24V (2x12V) / 7.2Ah / external charger
· Charging time: approx. 4.5h = 80% / 8h = 100%
Fully charged, a 30kg e-bike can be lifted
be lifted approx. 80 times.
· Mobile: integrated transport rollers
· Including base mounting plate with a 50 mm inner diameter mount
· European production / CE mark

You can test the BM-60 e-bike lift at our company by making an appointment by telephone. Our address is:

by,schulz GmbH

Bühlerstr. 121
66130 Saarbrücken

After written order receipt and order confirmation, the delivery time for stock items is approx. 10 days

The delivery time for repeat orders / pre-orders is approx. 8-10 weeks.

Forwarder shipping
Per piece on pallet / freight Germany-wide 149€ net.
Costs for shipping within Europe on request.

The registered brand e-Bikelifter is distributed throughout Europe by the:

by,schulz GmbH, Bühler Straße 121, 66130 Saarbrücken, Germany

______________

In Switzerland, the e-Bikelifter is distributed by:


Velok AG, Hardstrasse 16, 8303 Bassersdorf, Switzerland

For over 25 years, the German company by,schulz has focused on the new development and improvement of systems and components in the bicycle sector in order to optimize the interaction between man and machine. With our award-winning and partially patented products, we have achieved a leading position in the market for sophisticated bicycle accessories.

As an original equipment supplier for bicycle manufacturers, wholesalers and dealers, many of our components are installed as standard. In addition, we have a broad network of dealers who successfully sell and install our systems for end customers. All products are developed by by.schulz in Saarbrücken, tried and tested until they are ready for series production and tested by independent testing institutes.
